Parameter

Specifications

Access mode

10/100Mbps

Standard

IEEE802.3 10Base-T Ethernet,IEEE802.3u100Base-TX/FX Fast Ethernet, IEEE802.3x Flow control,IEEE802.1q VLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree

Wavelength

Mulitmode:850/1310nm; Single-mode:1310/1550nm (Option)

Transmission distance

multi-mode: 2 km; single-mode:20~120km; Category-5 twisted pairs: 100m

Port

One RJ45 port:  For connecting STP/UTP category-5 twisted pairs

One optical port: MM: SC/ST (50, 62.5/125μm); SM: SC/FC (9/125μm)

Conversion means

Media conversion, store-and-forward/cut-through

MAC address table

1K

Buffer space

1Mbit

Flow control

Full duplex: flow control; Half duplex: back pressure

Delay

Store-and-forward: 9.6μs; cut-through: 0.9μs

BER

<19-9

MTBF

100,000 hours

LED indicator

PWR (power supply); FX LINK/ACT (optical link/action)

FDX (FX full duplex), TP LINK/ACT (twisted pairs link/action)

TP 100 (100M transmission rate of twisted pairs),

FX 100 (100M transmission rate of optical fiber)

Power supply

DC5V 1A (external), AC220 0.5A/DC-48 (internal)

Power consumption

<2W

Operating temperature

-10~55ºC

Operating humidity

5%~90%

Maintainingtemperature

-40~70ºC

Maintaining humidity

5% ~ 90% non-condensing

Dimensions

26mm (H) * 70mm (W) * 94 mm (D) (external power supply)

30mm (H) * 110mm (W) * 140 mm (D) ( internal power supply)
