| Image Sensor |
1/3″ Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR on |
| Shutter Time |
1/3 s to 1/100,000 s |
| Day & Night |
ICR Cut |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens |
Fixed focal lens, 2.8, 4, and 6 mm optional |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| DORI |
DORI |
| Illuminator |
IR |
| Supplement Light Range |
-2I: up to 60 m<br> -4I: up to 80 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Video |
|
| Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)<br> 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)<br> 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)<br> 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.265/H.264/H.264+/H.265+<br> Sub-stream: H.265/H.264/MJPEG<br> Third stream: H.265/H.264 |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
Yes |
| Region Of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Network |
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE 10, IE 11<br> Plug-in free live view : Chrome 57.0+, Firefox 52.0+<br> Local service: Chrome 57.0+, Firefox 52.0+ |
| Image |
|
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) |
120 dB |
| SNR |
≥ 52 dB |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Interface |
|
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in microSD, up to 512 GB |
| Reset Key |
Yes |
| Event |
|
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event |
Line crossing detection, intrusion detection, supports human and vehicle targets classification, face detection |
| Linkage |
Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email |
| General |
|
| Power |
-2I: 12 VDC ± 25%, 0.71 A, max. 8.5 W<br> PoE: 802.3af, 36 V to 57 V, 0.27 A to 0.17 A, max. 9.5 W <br> -4I: 12 VDC ± 25%, 1.0 A, max. 11.5 W, PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W |
| Material |
Aluminum alloy body<br> Sun shield, IR cover: plastic |
| Dimension |
Ø105 × 299.7 mm (Ø4.1″ × 11.8″) |
| Package Dimension |
386 × 156 × 155 mm (15.2″ × 6.2″ × 6.2″) |
| Weight |
Approx. 1070 g (2.4 lb.) |
| With Package Weight |
Approx. 1589 g (3.5 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages |
| General Function |
Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
| Approval |
EMC: FCC, CE-EMC, RCM, IC, KC<br> Safety: UL, CB, CE-LVD, BIS, LOA<br> Environment: CE-RoHS, WEEE, Reach<br> Protection: IP67 |
