| Image Sensor |
2 × 1/2.5″ Progressive Scan CMOS |
| Max. Resolution |
3632 × 1632 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time |
1/3 s to 1/100,000 s |
| Angle Adjustment |
Pan: 0° to 30°, tilt: -75° to 75° |
| Lens Type |
Fixed focal lens, dual lens, 2.8 mm |
| Focal Length & FOV |
2.8 mm, horizontal FOV: 180°, vertical FOV: 81° |
| Lens Mount |
M12 |
| Iris Type |
Fixed |
| Aperture |
F1.0 |
| Depth Of Field |
2 m to ∞ |
| DORI |
2.8 mm, D: 45 m, O: 17.5 m, R: 9 m, I: 4.5 m |
| Illuminator |
White Light |
| Supplement Light Range |
Up to 30 m |
| Smart Supplement Light |
Yes |
| Video |
|
| Main Stream |
50 Hz: 20 fps (3632 × 1632) |
|
60 Hz: 20 fps (3632 × 1632) |
| Sub-Stream |
50 Hz: 20 fps (1200 × 536, 960 × 432) |
|
60 Hz: 20 fps (1200 × 536, 960 × 432) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264 |
|
Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region Of Interest (ROI) |
1 fixed region(s) for main stream |
| Audio |
|
| Audio Type |
Mono sound |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726) |
|
32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Network |
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, |
|
IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, Websocket, Websockets |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
| User/Host |
Up to 32 users |
|
3 user levels: administrator, operator, and user |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), |
|
watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest |
|
authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, |
|
security audit log, TLS 1.2, host authentication (MAC address) |
| Network Storage |
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
|
Together with high-end Hikvision memory card, memory card encryption and health detection are |
|
supported |
| Client |
iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser |
Plug-in required live view: IE 10, IE 11, |
|
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, |
|
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image |
|
| Image Parameters Switch |
Yes |
| Image Settings |
Saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software |
|
or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Wide Dynamic Range (WDR) |
130 dB |
| SNR |
≥ 52 dB |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Privacy Mask |
4 programmable polygon privacy masks |
| Interface |
|
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-In Microphone |
Yes |
| Built-In Speaker |
Max. power consumption: 1.2 W, max. sound pressure level: 10 cm: 95 dB |
| Audio |
|
| Alarm |
1 input(s), 1 output(s) (max. 24 VDC/24 VAC, 1 A) |
| Reset Key |
Yes |
| Event |
Basic Event: Motion detection (support alarm triggering by specified target types (human and |
|
vehicle)), alarm input and output, flashing alarm light output, audible alarm output, exception |
|
Smart Event: Line crossing detection, intrusion detection, region entrance detection, region |
|
exiting detection (support alarm triggered by specified target types (human and vehicle)), |
|
scene change detection |
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, |
|
trigger recording, trigger capture, audible warning, white light flashing |
| General |
|
| Power |
12 VDC ± 25%, 0.88 A, max. 10.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, |
|
PoE: 802.3af, Class 3, 36 V to 57 V, 0.35 A to 0.22 A, max. 12.5 W |
| Material |
Base: metal, cover: metal |
| Dimension |
Ø140 mm × 145.6 mm (Ø5.5 × 5.7″) |
| Package Dimension |
230 mm × 230 mm × 230 mm (9″ × 9″ × 9″) |
| Weight |
Approx. 920 g (2.0 lb.) |
| With Package Weight |
Approx. 1680 g (3.7 lb.) |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, |
|
Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, |
|
Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, |
|
Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Anti-banding, heartbeat, mirror, flash log, pixel counter |
| Flashing Light |
Yes |
| Approval |
|
| EMC |
FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: |
|
2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7 |
| Safety |
UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Environment |
|
| CE-RoHS |
2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006 |
| Protection |
IP67: IEC 60529-2013 |
