Image Sensor |
1/2.4″ Progressive Scan CMOS |
Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
Shutter Time |
1/3 s to 1/100,000 s |
Day & Night |
IR cut filter |
Max. Resolution |
3200 × 1800 |
Lens |
|
– Lens Type |
Varifocal lens, motorized lens, 2.8 to 12 mm |
– Focal Length & FOV |
2.8 to 12 mm, horizontal FOV 106° to 35°, vertical FOV 56° to 20° |
– Lens Mount |
Ø14 |
– Iris Type |
Fixed |
– Aperture |
F1.6 |
DORI |
|
– 2.8 to 12 mm |
Wide: D: 68 m, O: 27 m, R: 13 m, I: 7 m |
|
Tele: D: 200 m, O: 79 m, R: 40 m, I: 20 m |
Illuminator |
|
– Supplement Light Type |
IR |
– Smart Supplement Light |
Yes |
– IR Wavelength |
850 nm |
– Supplement Light Range |
Up to 40 m |
Video |
|
– Main Stream |
50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
|
60 Hz: 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
– Sub-Stream |
50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360) |
|
60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360) |
– Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
|
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
Video Compression |
Main stream: H.265/H.264/H.264+/H.265+ |
|
Sub-stream: H.265/H.264/MJPEG |
|
Third stream: H.265/H.264 |
Video Bit Rate |
32 Kbps to 16 Mbps |
H.264 Type |
Baseline Profile/Main Profile/High Profile |
H.265 Type |
Main Profile |
Bit Rate Control |
CBR/VBR |
Scalable Video Coding |
H.264 and H.265 encoding |
Region Of Interest (ROI) |
1 fixed region for main stream and sub-stream |
Audio |
|
– Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
– Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
– Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
– Environment Noise Filtering |
Yes |
Network |
|
– Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
– Simultaneous Live View |
Up to 6 channels |
– API |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
Client |
iVMS-4200, Hik-Connect, Hik-Central |
Web Browser |
Plug-in required live view: IE 10, IE 11, |
|
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, |
|
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
Image |
|
– Image Parameters Switch |
Yes |
– Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
– Day/Night Switch |
Day, Night, Auto, Schedule |
– Image Enhancement |
BLC, HLC, 3D DNR |
– SNR |
≥ 52 dB |
– Wide Dynamic Range (WDR) |
120 dB |
– Privacy Mask |
4 programmable polygon privacy masks |
Interface |
|
– Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
– Audio |
1 input (line in), 1 output (line out) |
– On-Board Storage |
Built-in memory card slot, support microSD card, up to 512 GB |
– Alarm |
1 input, 1 output (max. 24 VDC/24 VAC, 1 A) |
– Reset Key |
Yes |
Event |
|
– Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
– Smart Event |
Line crossing detection, intrusion detection, face detection |
– Linkage |
Upload to FTP/memory card/NAS, notify surveillance center, trigger recording, trigger capture, send email, audible warning, trigger alarm output |
General |
|
– Material |
Upper cover and base: metal, bubble: plastic |
– Dimension |
Ø153.3 mm × 111.6 mm (Ø6.1 × 4.4″)” |
– Package Dimension |
244 mm × 174 mm × 173 mm (9.7″ × 6.9″ × 6.9″) |
– Weight |
Approx. 885 g (1.9 lb.) |
– With Package Weight |
Approx. 1479 g (3.1 lb.) |
– Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
– Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
General Function |
Heartbeat, mirror, password reset via email, pixel counter, anti-flicker |
Power |
12 VDC ± 25%, 0.88 A, max. 10.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 12.5 W |
Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
Approval |
|
– EMC |
FCC, CE-EMC, RCM, IC, KC |
– Safety |
UL, CB, CE-LVD |
– Environment |
CE-RoHS, WEEE, Reach |
– Protection |
IP67, IK10 |
