| Image Sensor |
1.3″ Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.005 Lux |
|
B/W: 0.001 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter |
| Angle Adjustment |
Pan: -90° to 90° |
|
Tilt: 0 to 60° (2.8 mm) |
|
Tilt: 0 to 70° (4/6 mm) |
|
Rotate: 0° to 355° |
| Lens |
Focal Length & FOV |
|
2.8 mm, Horizontal FOV 98.2° |
|
4 mm, Horizontal FOV 78.8° |
|
6 mm, Horizontal FOV 49.1° |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| DORI |
D: 61.1 m |
|
O: 24.2 m |
|
R: 12.2 m |
|
I: 6.1 m |
| Illuminator |
IR |
| Supplement Light Range |
Up to 10 m |
| Smart Supplement Light |
Yes |
| Video |
Main Stream |
|
50 Hz: 25 fps |
|
60 Hz: 24 fps |
| Sub-Stream |
50 Hz: 25 fps |
|
60 Hz: 24 fps |
| Third Stream |
50 Hz: 25 fps |
|
60 Hz: 24 fps |
| Video Compression |
H.265/H.264 |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region Of Interest (ROI) |
4 fixed region(s) for each stream |
| Target Cropping |
Yes |
| Audio |
Audio Compression |
|
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw) |
|
16 Kbps (G.722.1) |
|
16 Kbps (G.726) |
|
32 to 192 Kbps (MP2L2) |
|
8 to 320 Kbps (MP3) |
|
16 to 64 Kbps (AAC-LC) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Network |
Protocols |
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
| Simultaneous Live View |
Up to 20 channels |
| API |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host |
Up to 32 users |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Network Storage |
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR), together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 11, Safari 12+, Chrome 57.0+, Firefox 52.0+ |
| Image |
Image Parameters Switch |
|
Yes |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule, Alarm Trigger |
| Wide Dynamic Range (WDR) |
120 dB |
| Image Enhancement |
BLC, HLC, 3D DNR, Defog |
| Privacy Mask |
8 programmable polygon privacy masks |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
| Interface |
Ethernet Interface |
|
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
|
Built-In Microphone |
|
2 built-in microphone(s) |
| Audio |
1 input (line in), 3.5 mm connector, 1 output (line out), 3.5 mm connector |
| Alarm |
1 input(s), 1 output(s) (max. 36 VDC, 30 mA) |
| RS-485 |
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Reset Key |
Yes |
| Event |
Basic Event, Smart Event |
| General |
Power |
|
12 VDC ± 20%, 0.58 A, max. 7.0 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: 802.3af, Type 1, Class 3, 36 V to 57 V, 0.25 A to 0.16 A, max. 9.0 W |
| Dimension |
164.3 mm × 84.6 mm × 67.4 mm (6.5″ × 3.3″ × 2.7″) |
| Package Dimension |
227 mm × 172 mm × 125 mm (8.9″ × 6.8″ × 4.9″) |
| Weight |
Approx. 770 g (1.7 lb.) |
| With Package Weight |
Approx. 1053 g (2.3 lb.) |
| Storage Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Function |
Heartbeat, mirror, flash log, password reset via email, password protection, one-key reset, anti-banding |
| Approval |
EMC, FCC, CE, RCM, IC, KC, UL, CB, BIS, LOA, CE-RoHS, WEEE, Reach |
| Protection |
IP67, IK10 |
