| Máy Ảnh |
|
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
ICR Cut |
| Min. Illumination |
Color: 0.009 Lux @ (F1.6, AGC ON) |
|
B/W: 0.0018 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Angle Adjustment |
P: -90 to 90° |
|
T: 0 to 60° (2.8mm), 0 to 70° (4/6mm) |
|
R: 0 to 355° |
| Image Sensor |
1/2.7″ Progressive Scan CMOS |
| Max. Resolution |
2560 x 1920 |
| Lens |
|
| Focal Length & FOV |
2.8mm @ F1.6 horizontal FOV 97°, vertical FOV 70° |
|
4 mm @ F1.6, horizontal FOV 79°, vertical FOV 57° |
|
6 mm @ F1.6, horizontal FOV 49°, vertical FOV 35° |
| Lens Mount |
M12 |
| Aperture |
F1.6 |
| DORI |
|
|
2.8 mm: D: 61.1 m, O: 24.2 m, R: 12.2 m, I: 6.1 m |
|
4 mm: D: 85.4 m, O: 33.9, R: 17.1 m, I: 8.5 m |
|
6 mm: D: 128.0 m, O: 50.8 m, R: 25.6 m, I: 12.8 m |
| Illuminator |
|
| Supplement Light Type |
IR |
| Supplement Light Range |
Up to 10 m |
| Smart Supplement Light |
Yes |
| IR Wavelength |
850 nm |
| Video |
|
| Main Stream |
50 Hz: 25 fps (2560 × 1920, 2048 × 1536) |
|
60 Hz: 30 fps (2560 × 1920, 2048 × 1536) |
| Sub-Stream |
50 Hz: 25 fps (640 × 480, 704 × 576) |
|
60 Hz: 30 fps (640 × 480, 704 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 640 × 480, 704 × 576) |
|
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 640 × 480, 704 × 480) |
| Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR/VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region Of Interest (ROI) |
4 fixed regions for each stream |
| Audio |
|
| Audio Type |
Stereo |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2) |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Network |
|
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Simultaneous Live View |
Up to 20 channels |
| API |
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Smooth Streaming |
No |
| User/Host |
Up to 32 users |
|
3 user levels: administrator, operator, and user |
| Security |
|
| Password protection |
Yes |
|
HTTPS encryption,802.1X authentication |
|
Watermark, IP address filter |
|
Basic and digest authentication for HTTP/HTTPS |
|
WSSE and digest authentication for ONVIF |
|
RTP/RTSP OVER HTTPS, Control Timeout Settings |
|
TLS 1.2 |
| Network Storage |
NAS (NFS, SMB/CIFS) |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
Plug-in required live view: IE8+ |
|
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ |
|
Local service: Chrome 41.0+, Firefox 30.0+ |
| Image |
|
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate, saturation, brightness, contrast, sharpness, white balance |
| Day/Night Switch |
Day, Night, Auto, Schedule, Triggered by Alarm In (-S) |
| Wide Dynamic Range (WDR) |
120 dB |
| Image Enhancement |
BLC, HLC, Defog, EIS, 3D DNR |
| Privacy Mask |
Yes |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
| Interface |
|
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Audio |
Without -S: 2 built-in mics |
|
-S: 2 built-in mics, 1 line in, 1 line out |
| Alarm |
-S: 1 input, 1 output (max. 36 VDC, 30mA) |
| RS-485 |
-S: 1 RS-485 interface, half duplex |
| Reset Key |
Yes |
| Event |
|
| Basic Event |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection |
|
Scene change detection, audio exception detection |
| Linkage |
Upload to FTP/NAS/memory card, send email |
| General |
|
| Power |
12 VDC, 0.9 A, max. 11 W, Ø5.5 mm coaxial power plug |
|
PoE: 802.3af, 36 V to 57 V, 0.3 A to 0.2 A, max. 11 W |
| Dimension |
164.3 × 84.6 × 67.4 mm (6.5″ × 3.3″ × 2.7″) |
| Package Dimension |
227 × 172 × 125 mm (8.9″ × 6.8″ × 4.9″) |
| Weight |
Approx. 770 g (1.7 lb.) |
| With Package Weight |
Approx. 1053 g (2.3 lb.) |
| Storage Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Startup And Operating Conditions |
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Language |
32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| General Function |
Mirror, anti-flicker, heartbeat |
| Heater |
Yes |
| Approval |
|
| EMC |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection |
Ingress protection: IP67, IK10 |
