| Hardware Specification |
| Interface |
WAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port |
| LAN Port: 4 x 10/100Mbps Auto MDI/MDI-X RJ45 port |
| Antenna |
Gain: 2 x Fixed 5dBi antenna |
| Orientation: Omni-directional |
| Power Button |
Power On/Off button at rear panel |
| WPS / Reset Button |
WPS / Reset button at front panel |
| Push the button at least 5 seconds to reset to factory default setting |
| WPS / Reset button at front panel |
PWR, SYS, WLAN, LAN x 4, WAN, WPS with green light |
| Wireless interface Specification |
| Standard |
Compliance with IEEE 802.11b/g/n |
| Frequency Band |
2.4~2.4835GHz |
| Extend Frequency |
DSSS |
| Modulation Type |
DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM) |
| Transmission Distance |
Indoor up to 100m |
| Outdoor up to 300m (It is limited to the environment) |
| Channel |
America / FCC: 2.414~2.462GHz (11 Channels) |
| Europe / ETSI: 2.412~2.472GHz (13 Channels) |
| Japan / TELEC: 2.412~2.484GHz (14 Channels) |
| RF Power |
≦20 dBm (EIRP) |
| Receive Sensitivity |
270M: -68dBm@10% PER |
| 130M: -68dBm@10% PER |
| 108M: -68dBm@10% PER |
| 54M: -68dBm@10% PER |
| 11M: -85dBm@8% PER |
| 6M: -88dBm@10% PER |
| 1M: -90dBm@8% PER |
| Wireless Management Features |
| Wireless Operation Mode |
AP, WDS (AP+Bridge), WISP Client Router |
| Encryption Security |
WEP (64/128/152-bit) encryption security |
| WPA-PSK / WPA2-PSK (TKIP/AES) |
| WPA / WPA2 (TKIP/AES) |
| WPA / WPA2 enterprise mode (802.1x authentication) |
| Wireless Security |
Provides wireless LAN ACL (Access Control List) filtering |
| Wireless MAC address filtering |
| Supports WPS (Wi-Fi Protected Setup ) |
| Enable / Disable SSID Broadcast |
| Wireless Advanced Features |
Supports 802.11e WMM (Wi-Fi Multimedia) |
| Supports Wireless Roaming (Mobility Feature) |
| Provides Wireless Statistics |
| Router Features |
| Internet Connection Type |
Shares data and Internet access for users by supporting the following protocols: |
| PPPoE, Dynamic IP, Static IP, Telstra Big Pond, PPTP / Russia PPTP, L2TP / Russia L2TP |
| Firewall |
NAT firewall with SPI (Stateful Packet Inspection) |
| NAT with ALG (Application Layer Gateway) |
| Built-in NAT server supporting Virtual Server, and DMZ |
| Built-in firewall with IP address filtering, Domain Name filtering, and |
| MAC address filtering |
| Supports ICMP-FLOOD, UDP-FLOOD, TCP-SYN-FLOOD filter, DoS protection |
| Routing Protocol |
Static Routing |
| VPN Pass-through |
PPTP, L2TP, IPSec |
| LAN |
Built-in DHCP server supporting static IP address distributing |
| Supports UPnP, Dynamic DNS |
| Supports Flow Statistics |
| IP & MAC Binding |
| IP / Protocol-Based Bandwidth Control |
| Session Number: Max. 5210 |
| OS Compatibility |
Windows 7 (32-bit/64-bit) |
| Windows Vista (32-bit/64-bit) |
| Windows XP |
| Mac OSX 10.4 and higher |
| Standards Conformance |
| IEEE Standards |
IEEE 802.11n (2T2R, up to 300Mbps) |
| IEEE 802.11g |
| IEEE 802.11b |
| IEEE 802.11i |
| IEEE 802.3 10Base-T |
| IEEE 802.3u 100Base-TX |
| IEEE 802.3x Flow Control |
| Others Protocols and Standards |
CSMA/CA, CSMA/CD, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP |
| Power Requirement |
9VDC, 0.6A |
| Material |
Plastic |
| Dimension |
174 x 110 x 23 mm |
| Weight |
280g |
