| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter; Blue glass module to reduce ghost phenomenon |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Lens |
Focal Length & FOV |
|
2.8 to 12 mm: Horizontal FOV: 114.5° to 41.8°; Vertical FOV: 59.3° to 23.6°; Diagonal FOV: 141.1° to 48° |
|
8 to 32 mm: Horizontal FOV: 42.5° to 15.1°; Vertical FOV: 23.3° to 8.64°; Diagonal FOV: 49.6° to 17.3° |
| Focus |
Auto, Semi-auto, Manual |
| Iris Type |
P-iris |
| Aperture |
2.8 to 12 mm: F1.2 to F2.5; 8 to 32 mm: F1.7 to F1.73 |
| DORI |
Wide: |
|
2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m |
|
8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 m |
|
Tele: |
|
2.8 to 12 mm: D (Detect): 149 m, O (Observe): 59.1 m, R (Recognize): 29.8 m, I (Identify): 14.9 m |
|
8 to 32 mm: D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m |
| Illuminator |
IR Wavelength: 850 nm |
|
Smart Supplement Light: Yes |
|
Supplement Light Range: 2.8 to 12 mm: 30 m; 8 to 32 mm: 50 m |
|
Supplement Light Type: IR |
| AI Open Platform |
Model Specification: Up to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model) |
| Video |
Main Stream: |
|
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720); 50 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
|
60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720); 60 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480); 60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Fifth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, Fifth stream: H.265/H.264/MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile, Main Profile, High Profile |
| H.265 Type |
Main Profile |
| Bit Rate Control |
CBR, VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region Of Interest (ROI) |
4 fixed regions for each stream |
| Target Cropping |
Yes |
| E-PTZ |
Support Patrol and Auto Tracking settings |
| Audio |
Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
|
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
|
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
|
Audio Type: Mono sound |
|
Environment Noise Filtering: Yes |
| Network |
API: Open Network Video Interface (Profile S, Profile G, Profile T, Profile M), ISAPI, SDK, ISUP |
|
Client: iVMS-4200, Hik-Connect, Hik-Central |
|
Network Storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
|
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
|
Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
|
Simultaneous Live View: Up to 20 channels |
|
User/Host: Up to 32 users, 3 user levels: administrator, operator, and user |
|
Web Browser: Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image |
Image Parameters Switch: Yes |
|
Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, white balance, AGC, adjustable by client software or web browser |
|
Day/Night Switch: Day, Night, Auto, Schedule, Alarm Trigger |
|
Wide Dynamic Range (WDR): 140 dB |
|
Image Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog |
|
SNR: ≥ 52 dB |
|
Privacy Mask: 8 programmable polygon privacy masks |
|
Image Stabilization: EIS |
|
Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
| Interface |
Video Output: 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
|
Ethernet Interface: 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
|
On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
|
Audio: 1 input (line in), 1 output (line out), 3.5 mm connector |
|
Built-In Microphone: Yes, 2 built-in microphones |
|
Alarm: 1 input, 1 output (max. 24 VDC, 1 A) |
|
RS-485: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
|
Reset Key: Yes |
|
Power Output: 12 VDC, max. 100 mA |
| Event |
Basic Event: Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error), video quality diagnosis, vibration detection |
|
Smart Event: scene change detection, audio exception detection, defocus detection |
|
Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning |
|
Deep Learning Function: Multi-Target-Type Detection, Face Capture, Face Comparison, Perimeter Protection, Heat Map, Queue Management, People Counting, Hard Hat Detection, Metadata, Regional People Counting, On/Off Duty Detection |
|
Regional People Counting: Supports up to 8 detection regions, and independent arming schedule and linkage method |
|
People Counting: Supports Multi-Dimension People Counting, supports counting, displaying and exporting the people flow data of entering, exiting and passing by, supports real-time uploading and uploading by statistic cycle, supports generating daily, weekly, monthly or annually reports, supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval, supports face feature deduplication, supports people flow data replenishment |
|
On/Off Duty Detection: Supports up to 8 detection regions, and independent arming schedule and linkage method, supports 2 detection modes: absence detection, on/off duty detection, supports parameter settings: person on duty, absence duration |
| General |
Power: With –Y: 12 VDC ± 20%, 1.23 A, max. 14.7 W, three-core terminal block; 24 VAC ± 20%, 0.91 A, max. 13.7 W, three-core terminal block; PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.27 A to 0.36 A, max. 15.0 W. Without –Y: 12 VDC ± 20%, 1.23 A, max. 14.7 W, two-core terminal block; 24 VAC ± 20%, 0.91 A, max. 13.7 W, two-core terminal block; PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.27 A to 0.36 A, max. 15.0 W |
|
Material: Aluminum alloy body |
|
Dimension: Ø162 mm × 141.8 mm (Ø6.4″ × 5.6″) |
|
Package Dimension: 251 mm × 215 mm × 189 mm (9.9″ × 8.5″ × 7.4″) |
|
Weight: Without -Y: approx. 1490 g (3.28 lb.); With -Y: approx. 1565 g (3.45 lb.) |
|
With Package Weight: Without -Y: approx. 2435 g (5.37 lb.); With -Y: approx. 2295 g (5.06 lb.) |
|
Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Startup And Operating Conditions: -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Language: 33 languages |
|
General Function: Heartbeat, mirror, password protection, one-key reset |
|
Heater: Yes |
|
Device Management: Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces |
| Approval |
EMC: FCC, CE-EMC, RC, IC, KC, Safety: UL, CB, CE-LVD, BIS, LOA, Environment: CE-RoHS, WEEE, Reach, Protection: IP67, IK10, Anti-Corrosion Protection: NEMA 4X, Automotive And Railway: EN50121-4, Other: PVC FREE, CC |
