| Image Sensor |
1/1.8″ Progressive Scan CMOS |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Time |
1 s to 1/100,000 s |
| Day & Night |
IR cut filter, Blue glass module to reduce ghost phenomenon |
| Lens |
– Focal Length & FOV: 3.8 to 16 mm, horizontal FOV: 109.1° to 29.6°, vertical FOV: 61.3° to 16.8°, diagonal FOV: 125.1° to 33.9° – Lens Mount: CS mount – Focus: Manual – Iris Type: P-iris – Aperture: 3.8 to 16 mm: F1.4, 11 to 40 mm: constant F1.4 throughout the zoom range |
| DORI |
Wide: 3.8 to 16 mm: D (Detect): 57.2 m, O (Observe): 22.7 m, R (Recognize): 11.4 m, I (Identify): 5.7 m 11 to 40 mm: D (Detect): 165.5 m, O (Observe): 65.7 m, R (Recognize): 33.1 m, I (Identify): 16.6 m Tele: 3.8 to 16 mm: D (Detect): 206.9 m, O (Observe): 82.1 m, R (Recognize): 41.4 m, I (Identify): 20.7 m 11 to 40 mm: D (Detect): 510.3 m, O (Observe): 202.5 m, R (Recognize): 102.1 m, I (Identify): 51 m |
| Illuminator |
– Supplement Light Type: IR – Supplement Light Range: 3.8 to 16 mm: 80 m, 11 to 40 mm: 120 m – Smart Supplement Light: Yes – IR Wavelength: 850 nm |
| AI Open Platform |
Model Specification: Up to 4 models, Model type: detection model, classification model, mixed model (detection model and classification model) |
| Video |
– Main Stream: 50 Hz: 25/50 fps, 60 Hz: 30/60 fps – Sub-Stream: 50 Hz/60 Hz: 25/30 fps – Third Stream/Fourth Stream/Fifth Stream: 50 Hz/60 Hz: 25/30 fps – Video Compression: Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, Fourth stream: H.265/H.264/MJPEG, Fifth stream: H.265/H.264/MJPEG – Video Bit Rate: 32 Kbps to 8 Mbps – H.264 Type: Baseline Profile, Main Profile, High Profile – H.265 Type: Main Profile – Bit Rate Control: CBR, VBR – Scalable Video Coding (SVC): H.264 and H.265 encoding – Region Of Interest (ROI): 4 fixed regions for each stream – Target Cropping: Yes – E-PTZ: Support Patrol and Auto Tracking settings |
| Audio |
– Audio Type: Mono sound – Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC – Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1/G.726), 32 to 192 Kbps (MP2L2), 8 to 320 Kbps (MP3), 16 to 64 Kbps (AAC-LC) – Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz – Environment Noise Filtering: Yes |
| Network |
– Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets – Simultaneous Live View: Up to 20 channels – API: Open Network Video Interface (Profile S, Profile G, Profile T, Profile M), ISAPI, SDK, ISUP – User/Host: Up to 32 users, 3 user levels: administrator, operator, and user – Security: Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Network Storage |
– NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) – Together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| Client |
– iVMS-4200, Hik-Connect, Hik-Central – Web Browser: Plug-in required live view: IE 10, IE 11, Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Image |
– Image Parameters Switch: Yes – Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, white balance, and AGC adjustable by client software or web browser – Day/Night Switch: Day, Night, Auto, Schedule, Alarm Trigger – Wide Dynamic Range (WDR): 140 dB – Image Enhancement: BLC, HLC, 3D DNR, Distortion Correction, Defog – SNR: ≥ 52 dB – Privacy Mask: 8 programmable polygon privacy masks – Image Stabilization: EIS – Picture Overlay: LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format |
| Interface |
– Video Output: 1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) – Ethernet Interface: 1 RJ45 100 M/1000 M self-adaptive Ethernet port – On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB – Audio: Without -R: 1 input (line in), 1 output (line out), 3.5 mm connector – Alarm: 2 inputs, 2 outputs (max. 24 VDC, 1 A) – RS-485: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) – Reset Key: Yes – Power Output: 12 VDC, max. 100 mA – Fiber Optical: With /F11: 1 LC fiber optical interface, SFP module, single mode, 20 km transmission distance, 1310 nm (TX) and 1550 nm (RX), 155 Mbps transmission rate |
| Event |
– Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error), video quality diagnosis – Smart Event: scene change detection, audio exception detection, defocus detection – Linkage: Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning – Deep Learning Function: Multi-Target-Type Detection, Face Capture, Face Comparison, Perimeter Protection, People Counting, Queue Management, Heat Map, Hard Hat Detection, Metadata, Regional People Counting, On/Off Duty Detection |
| General |
– Power: With F11: 24 VDC ± 20%, 0.98 A, max. 23.3 W, three-core terminal block, 24 VAC ± 20%, 1.05 A, max. 25 W, three-core terminal block, PoE: IEEE 802.3bt, Type3, Class 5, 42.5 V to 57 V, 0.63 A to 0.47 A, max. 26.4 W Without /F11: 24 VDC ± 20%, 0.9 A, max. 21.6 W, three-core terminal block, 24 VAC ± 20%, 0.93 A, max. 22.1 W, three-core terminal block, PoE: IEEE 802.3bt, Type3, Class 5, 42.5 V to 57 V, 0.58 A to 0.44 A, max. 24.6 W – Material: Aluminum alloy body, PP sun shield, PC front panel – Dimension: 465.3 mm × 169.2 mm × 164.7 mm (18.3″ × 6.7″ × 6.5″) – Package Dimension: 615 mm × 360 mm × 225 mm (24.2″ × 14.2″ × 8.9″) – Weight: Approx. 3800 g (8.4 lb.), With Package Weight: Approx. 6000 g (13.2 lb.) – Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) – Startup And Operating Conditions: -40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing) – Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian – General Function: Heartbeat, mirror, password protection, one-key reset – Heater: Yes – Device Management: Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces – Approval: EMC: FCC, CE-EMC, RCM, IC, KC, Safety: UL, CB, CE-LVD, BIS, LOA, Environment: CE-RoHS, WEEE, Reach, Protection: IP66, IK10, Anti-Corrosion Protection: With -Y: NEMA 4X(NEMA 250-2018), Automotive And Railway: With -R: EN50121-4, Other: PVC FREE, CC: Common Criteria, Assurance Level: EAL2 + ALC_FLR.2 |
